Network HD Camera

KC-T4B17C-SG-DJ

4MP
Built-in pickup speaker
Two-way intercom
Aluminum Alloy Material
Product description:
INQUIRY

Chip parameters
Model	KC-T4B17C-SG-DJ
Name	Dual light cctv camera
System structure	Embedded RTOS design, single core 32-bit DSP, pure hardware compression, watchdog, 8MB FLASH, 64MB built-in DDR
Sensor	4MP 1/3" CMOS, color 0.001Lux@F1.2 (AGC ON), black and white 0Lux (IR ON)
Video processing	H.265+/H.265/H.264 video encoding, support dual stream, AVI format; support stream 200k~8000k bps adjustable, support P system and N system
Frame rate	4MP 20 Frame
Image output	Main stream: 2560×1440, 2304×1296, 1920×1080, 1280×960, 1280×720
Image output	Sub stream: D1, 800×448, 640×480, 640×360, 352×288
Audio processing	G.711 codec standard,, support audio and video synchronization
Supported protocols	HTTP, TCP/IP, IPv4, DHCP, NTP, RTSP, ONVIF, P2P, PPTP, GB/T28181 etc.
Service functions	Support Web configuration, support OSD, support real-time video transmission, support motion detection alarm linkage, support center reminder and screen pop-up linkage after motion detection alarm; support remote monitoring software (Seetong) and other system applications
ONVIF protocol	Support
Client	iOS, Android mobole client, PC client
Other functions	Human detection; Light alarm
External parameters
Fill light	4 infrared lights + 4 warm light lights
External port	1 RJ45 Ethernet interface, 10/100M adaptive, 8KV anti-static ability; support
Lightning protection	Power supply and network comprehensive lightning protection, front-end power input lightning protection, anti-static, anti-reverse connection, and support 18V shutdown voltage protection
Power supply	DC12V power input interface, anti-reverse connection, and support 18V shutdown voltage protection
Working environment	-40℃～+85℃
Protection level	IP20
Power consumption	Dayt <1.5W Max Night <3.3Max
Dimensions (mm)	11011096
Weight	Body weight: 210g Packaging weight: 270g
