Chip Specifications |
|
| System Structure | Embedded RTOS design, Single core 32-bit DSP,pure hardware compression,Watchdog,8Mb FLASH,64Mb built-in DDR |
|
Sensor |
3.0MP 1/2.7" CMOS,color 1.0Lux@F2.0,B/W 0 Lux@F2.0 |
|
镜头 |
F2.0 4mm/6mm 可选 |
|
Video Process |
H.265+/H.265/H.264 video coding, support dual stream, AVI format; code stream 200k~8000k bps adjustable,low bit rate,support PAL and NTSC |
|
Frame Rate |
3.0MP @20 frames,2.0MP @30 frames |
|
Image Output |
Main stream: 2304×1296,1920×1080,1280×960,1280×720 |
|
Code stream: 800×448,640×480,640×360,352×288 |
|
|
Audio Interface |
1 channel input,support mic or pickup input;1 channel output, support headset or amplifier play |
|
Audio Process |
G.711 CODE standard, support 2-way voice talkback, audio and video synchronization |
|
Network Protocol |
Support HTTP,TCP/IP,IPv4,DHCP,NTP,RTSP,ONVIF,P2P,PPTP,GB/T28181,etc. |
|
Business Function |
Configure by WEB, OSD(on screen display),real-time video transmission, motion detection and alarm linkage ,center prompt and picture pop-up after alarm; support remote surveillance client software(Seetong),etc. |
|
ONVIF Protocol |
Support |
|
Client |
Support mobile monitoring(iOS, Android) and PC client |
|
Others |
Human body detection,Light alarm |
| External Specifications | |
|
Fill light |
2*Dot-Matrix LED with dual led chip ,补光距离 20米 |
|
External Interface |
1*RJ45 Ethernet interface,10/100M self-adaption,8KV anti-static electric capacity |
|
Lightning Protection |
Surge protection in power supply and network; lightning protection,anti-static and anti-reverse connection of front end power input; support 18V turn off voltage protection |
|
Power |
DC12V / 802.11af 48V POE （optional）+-25%; support anti-reverse connection,over-voltage and overload protection, short-circuit protection |
|
Working Environment |
-40℃～+85℃ |
|
Protection Grade |
IP50 |
|
Size(mm) |
110*110*96 |
|
Power Consumption |
Day＜1W Max ; Night＜3.3 Max |
|
Weight |
Net weight: 222g； Gross Weight:282g |
