Specifications |
|
| System structure |
Embedded LINUX design, pure hardware decoding, watchdog, hard disk storage, HDMI high-definition display, IP network video access |
|
Video input |
High-definition IPC access, supports dual-stream access for each IPC, supports automatic search, automatic addition, automatic recording, automatic preview, and zero debugging; Access bandwidth 64Mbps |
|
Video output |
1 HDMI output, 1 VGA output, same source as HDMI;
|
| Recording resolution | supports 720P/960P/1080P/3MP/4MP/5MP/8MP |
|
Video decoding |
Supports H.265+/H.265/H.264NVR synchronous playback 2 channels (2*8MP);
|
| Audio |
Standard G.711, supports audio and video recording;
|
|
Storage management |
1 SATA interface, each interface supports a hard disk with a maximum capacity of 14TB,; supports scheduled recording, motion detection linkage recording/alarm linkage recording/cross-border recording/regional intrusion recording/intelligent face recording/intelligent license plate recording/intelligent human-shaped recording/intelligent car-shaped recording |
|
User management |
supports up to 38 users |
|
Network interface |
1 RJ45 Ethernet interface, supports 10/100M adaptive; supports TCP/IP, IPv4, DHCP, NTP, RTSP, ONVIF, P2P, SMTP, GB28181 and other network protocol |
|
Business functions |
Support preview/recording/forwarding/remote service, support alarm linkage, support Seetong client remote monitoring software; support Seetong cloud service |
|
External parameters |
|
|
Front panel |
Supports 3 status indicators for power, recording, and network transmission |
| External ports | 2 USB2.0 interfaces (rear); Support mouse, USB upgrade, import and export |
|
Working humidity |
10%~90% |
|
Working temperature |
-10℃~+55℃ |
|
Weight |
608g |
| Power consumption | ≤3W power consumption (excluding hard disk) |
|
Power supply |
Input DC +12V/2A |
